M.S. Rectangular Hollow Section
| RHS DxB mm |
Thickness mm |
Sec Area A cm2 |
Unit W kg/m |
Moment of Inertia | Radius of Gyration | Elastic Modulus | Torsional Constants | Outer Surface | ||||
| lxx cm4 |
lyy cm4 |
rxx cm |
ryy cm |
Zxx cm3 |
Zyy cm3 |
J cm4 |
B cm3 |
Area per m m2 |
||||
|
50 x 25 |
2.00 |
2.74 |
2.15 |
8.38 |
2.81 |
1.75 |
1.01 |
3.35 |
2.25 |
6.79 |
3.79 |
0.142 |
|
2.60 |
3.46 |
2.71 |
10.16 |
3.36 |
1.71 |
0.99 |
4.06 |
2.69 |
8.27 |
4.53 |
0.137 |
|
|
3.20 |
4.13 |
3.24 |
11.63 |
3.80 |
1.68 |
0.96 |
4.65 |
3.04 |
9.52 |
5.12 |
0.134 |
|
|
4.00 |
4.95 |
3.88 |
13.13 |
4.23 |
1.63 |
0.92 |
5.25 |
3.38 |
10.86 |
5.69 |
0.129 |
|
|
60 X 40 |
2.60 |
4.76 |
3.73 |
22.76 |
12.09 |
2.19 |
1.59 |
7.59 |
6.05 |
25.59 |
9.83 |
0.187 |
|
2.90 |
5.25 |
4.12 |
24.74 |
13.11 |
2.17 |
1.58 |
8.25 |
6.56 |
28.02 |
10.66 |
0.185 |
|
|
3.60 |
6.35 |
4.98 |
28.90 |
15.23 |
2.13 |
1.55 |
9.63 |
7.62 |
33.30 |
12.41 |
0.181 |
|
|
4.50 |
7.67 |
6.02 |
33.31 |
17.44 |
2.08 |
1.51 |
11.10 |
8.72 |
39.34 |
14.29 |
0.177 |
|
|
66×33 |
2.60 |
4.70 |
3.69 |
25.15 |
8.43 |
2.31 |
1.34 |
7.62 |
5.11 |
20.75 |
8.71 |
0.185 |
|
2.90 |
5.19 |
4.07 |
27.33 |
9.12 |
2.29 |
1.33 |
8.28 |
5.53 |
22.65 |
9.43 |
0.183 |
|
|
3.60 |
6.28 |
4.93 |
31.87 |
10.52 |
2.25 |
1.29 |
9.66 |
6.37 |
26.71 |
10.90 |
0.179 |
|
|
4.50 |
7.58 |
5.95 |
36.64 |
11.93 |
2.20 |
1.25 |
11.10 |
7.23 |
31.21 |
12.43 |
0.175 |
|
|
80×40 |
2.60 |
5.80 |
4.55 |
46.58 |
15.74 |
2.84 |
1.65 |
11.65 |
7.87 |
38.50 |
13.46 |
0.227 |
|
3.20 |
7.01 |
5.50 |
54.94 |
18.41 |
2.80 |
1.62 |
13.74 |
9.21 |
45.83 |
15.78 |
0.224 |
|
|
4.00 |
8.55 |
6.71 |
64.79 |
21.49 |
2.75 |
1.59 |
16.20 |
10.74 |
54.77 |
18.49 |
0.219 |
|
|
4.80 |
10.01 |
7.85 |
73.22 |
24.03 |
2.71 |
1.55 |
18.30 |
12.02 |
62.81 |
20.79 |
0.215 |
|
|
96×48 |
3.20 |
8.54 |
6.71 |
98.61 |
33.28 |
3.40 |
1.97 |
20.54 |
13.87 |
82.13 |
23.82 |
0.272 |
|
4.00 |
10.47 |
8.22 |
117.54 |
39.32 |
3.35 |
1.94 |
24.49 |
16.38 |
99.11 |
28.24 |
0.267 |
|
|
4.80 |
12.31 |
9.66 |
134.35 |
44.55 |
3.30 |
1.90 |
27.99 |
18.56 |
114.80 |
32.14 |
0.263 |
|
|
122×61 |
3.60 |
12.32 |
9.67 |
232.61 |
78.83 |
4.34 |
2.53 |
38.13 |
25.84 |
193.91 |
44.50 |
0.347 |
|
4.50 |
15.14 |
11.88 |
27894 |
93.78 |
4.29 |
2.49 |
45.73 |
30.75 |
235.39 |
53.13 |
0.343 |
|
|
5.40 |
17.85 |
14.01 |
320.83 |
107.03 |
4.24 |
2.45 |
52.60 |
35.09 |
274.29 |
60.89 |
0.338 |
|
|
145x82 |
4.80 |
20.28 |
15.92 |
555.16 |
228.50 |
5.23 |
3.36 |
76.57 |
55.73 |
534.27 |
94.45 |
0.429 |
|
5.40 |
22.60 |
17.74 |
610.85 |
250.59 |
5.20 |
3.33 |
84.26 |
61.12 |
592.70 |
103.81 |
0.426 |
|
|
172×92 |
4.80 |
23.83 |
18.71 |
917.13 |
346.91 |
6.20 |
3.82 |
106.64 |
75.41 |
826.04 |
128.85 |
0.503 |
|
5.40 |
26.59 |
20.88 |
1012.47 |
381.74 |
6.17 |
3.79 |
117.73 |
82.99 |
918.10 |
142.04 |
0.500 |
|
|
200×100 |
4.00 |
22.95 |
18.01 |
1199.71 |
410.78 |
7.23 |
4.23 |
119.97 |
82.16 |
991.47 |
141.46 |
0.579 |
|
5.00 |
28.36 |
22.26 |
1459.25 |
496.94 |
7.17 |
4.19 |
145.93 |
99.39 |
1216.96 |
171.53 |
0.574 |
|
| 6.00 |
33.63 |
26.40 |
1703.31 |
576.91 |
7.12 |
4.14 |
170.33 |
115.38 |
1434.03 |
199.68 |
0.569 |
|
|
8.00 |
43.79 |
34.38 |
2146.21 |
719.19 |
7.00 |
4.05 |
214.62 |
143.84 |
1843.86 |
250.68 |
0.559 |
|
|
220×140 |
4.00 |
27.75 |
21.78 |
1892.62 |
947.66 |
8.26 |
5.84 |
172.06 |
135.38 |
2004.80 |
223.74 |
0.699 |
|
5.00 |
34.36 |
26.97 |
2313.45 |
1155.26 |
8.21 |
5.80 |
210.31 |
165.04 |
2468.51 |
272.71 |
0.694 |
|
|
6.00 |
40.83 |
32.05 |
2714.10 |
1351.70 |
8.15 |
5.75 |
246.74 |
193.10 |
2914.71 |
318.93 |
0.689 |
|
|
8.00 |
53.39 |
41.91 |
3456.31 |
1712.25 |
8.05 |
5.66 |
314.21 |
244.61 |
3270.10 |
378.40 |
0.679 |
|
|
240x120 |
4.00 |
27.75 |
21.78 |
2110.72 |
725.35 |
8.72 |
5.11 |
175.89 |
120.89 |
1736.39 |
208.03 |
0.699 |
|
5.00 |
34.36 |
26.97 |
2579.67 |
882.47 |
8.67 |
5.07 |
214.97 |
147.08 |
2138.48 |
253.55 |
0.694 |
|
|
6.00 |
40.83 |
32.05 |
3025.91 |
1030.45 |
8.61 |
5.02 |
252.16 |
171.74 |
2528.39 |
296.70 |
0.689 |
|
|
8.00 |
53.39 |
41.91 |
3851.84 |
1299.95 |
8.49 |
4.93 |
320.99 |
216.66 |
3272.90 |
376.29 |
0.679 |
|
|
260x180 |
6.00 |
50.43 |
39.59 |
4855.87 |
2763.43 |
9.81 |
7.40 |
373.53 |
307.05 |
5619.50 |
501.05 |
0.849 |
|
8.00 |
66.19 |
51.96 |
6238.69 |
3538.10 |
9.71 |
7.31 |
479.90 |
393.12 |
6821.23 |
620.13 |
0.839 |
|
|
10.00 |
81.43 |
63.92 |
7509.5 |
4244.26 |
9.60 |
7.22 |
577.65 |
471.58 |
8972.14 |
760.42 |
0.834 |
|
|
12.00 |
96.14 |
75.47 |
8672.42 |
4884.94 |
9.50 |
7.13 |
667.11 |
542.77 |
10150.39 |
875.12 |
0.829 |
|
|
300×150 |
6.00 |
51.63 |
40.53 |
6073.51 |
2079.57 |
10.85 |
6.35 |
404.90 |
277.28 |
5034.64 |
478.20 |
0.869 |
|
8.00 |
67.79 |
53.22 |
7807.95 |
2654.12 |
10.73 |
6.26 |
520.53 |
353.88 |
6559.05 |
612.64 |
0.859 |
|
|
10.00 |
83.43 |
65.49 |
9403.90 |
3173.71 |
10.62 |
6.17 |
626.93 |
423.16 |
8011.67 |
736.01 |
0.848 |
|
|
12.00 |
98.54 |
77.35 |
10866.10 |
3641.00 |
10.50 |
6.08 |
724.41 |
485.47 |
9110.72 |
829.98 |
0.838 |
|
|
300x200 |
6.00 |
57.63 |
45.24 |
7370.23 |
3962.19 |
11.31 |
8.29 |
491.35 |
396.22 |
8186.02 |
650.85 |
0.969 |
|
8.00 |
75.79 |
59.50 |
9513.66 |
5097.04 |
11.20 |
8.20 |
634.24 |
509.70 |
10722.83 |
839.51 |
0.959 |
|
|
10.00 |
93.43 |
73.34 |
11507.24 |
6144.30 |
11.10 |
8.11 |
767.15 |
614.43 |
13169.70 |
1015.43 |
0.948 |
|
|
12.00 |
110.54 |
86.77 |
13355.84 |
7107.43 |
10.99 |
8.02 |
890.39 |
710.43 |
15215.03 |
1160.24 |
0.938 |
|
